OXYGEN TYPE OZONE MACHINE KT-EY custom series

Product Introduction

Intelligent PLC one-piece unit of ozone system includes air supply unit and treasure, similar to the principle of fission and compressed air through a pipe to the all removal filter, after ordinary filter, in the primary except water by freeze drying machine.electronic drain valve automatically by the precision filter drainage, depth in addition to water after drying cylinder, make the air dew point is achieved, After the dust filter to make dust particles less than fum, qualified gas source in the pressure reducing valve into the oxygen generator, producing 90%+3 purity of oxygen, into the ozone generator, through high pressure ionization to produce ozone, through its mixing device and water to fully ease.

Product composition

The ozone system built-in: ozone generator. Oxygen generator adsorption drying module, filter/gas reducing valve, air source control system, oxygen purity detection.anti-backwater system,ozone mixed negative pressure system detection PLC system integrated control monitoring function fault feedback system, Multifunctional selection, support for customization

Product Features

(1) Two system host control, built-in accessories, integrated design, compared with the traditional split multi-host accessories.easier installation, smaller footprint

(2) Program adjustment control, by the traditional manual knob adjustment (range 15%-100%, accuracy 5%), optimized to PLC adjustment (range 0-100%,accuracy 1%)

(3) Siemens PLC intelligent regulation, real-time monitoring of ozone operating status, PLC monitoring of various data storage

history failures.

(4) Optimize monitoring function fault feedback, more safe and convenient operation, more durable machine; Compared with the traditional five protection mechanisms, the following functions are added: air source pressure protection; Intake temperature protection: intake dew point detection; Oxygen generator purity detection; Mixed system negative pressure monitoring; Backwater system monitoring and automatic discharge; 0zone tube cooling water time monitoring rod;, Operating parameters, fault history records:

(5) Red flag negative pressure meter with contacts, real-time monitoring, the first time to inform the cause of concentration change, no manual troubleshooting causes, improve efficiency.
